Three-phase electric motor 7.5 kW 970 rpm

New -17 %

Three-phase electric motor 7.5 kW 970 rpm

Description
Reviews

Three-phase asynchronous electric motor with squirrel-cage rotor. Designed for continuous S1 duty. The motor is 6-pole, therefore at 50 Hz its rated speed is approximately 970 rpm.

Parameter	Value
Model:	Y160M-6
Rated voltage, V:	380
Speed, rpm:	~970
Rated power, kW/HP:	7.5 / 10
Frequency, Hz:	50
Insulation class:	B
Protection class:	IP44
Duty type:	S1
Connection:	Δ (delta)
Standard:	JB/T 10391-2008
Noise level, dB(A):	85

Y160M-6 (7.5 kW, ~970 rpm), compared with Y132S2-2 (7.5 kW, ~2900 rpm), runs at a lower speed but develops approximately 3 times higher torque, making it better suited for heavy-duty drives and higher loads.
